Bathroom tile installation requires more than just a tile saw and adhesive. Modern porcelain and ceramic tiles are harder, larger, and more demanding than traditional materials, which means professional installers need reliable diamond tools for drilling, cutting, and finishing.

A typical bathroom renovation may involve dozens of different tasks: drilling holes for shower valves, creating openings for pipes, trimming tiles around corners, and adjusting edges for a perfect fit.

The challenge is that each task often requires a different diamond tool size. Many tile contractors end up purchasing individual drill bits, blades, and accessories separately. Over time, this creates higher tool costs, storage problems, and the frustration of searching for the right size when working on-site.

A complete diamond tool kit designed for tile installation helps solve these problems by keeping the most commonly used sizes organized and ready for every project.

What Diamond Tools Do Tile Installers Need for Bathroom Projects?

Most bathroom tile jobs require three essential types of diamond tools:

• Diamond drill bits for plumbing holes and fixture installation
• Diamond cutting blades for tile trimming
• Diamond grinding discs for edge finishing and adjustments

Choosing the correct tool size and using the right operating speed can significantly improve cutting performance and reduce the risk of damaging expensive porcelain tiles.

Choosing the Right Diamond Drill Bit Sizes for Porcelain Tile

Porcelain tile is extremely dense and difficult to drill with standard drill bits. Unlike softer ceramic materials, porcelain requires diamond cutting edges that gradually grind through the surface.

The correct diamond drill bit size depends on the installation task.

Common Diamond Drill Bit Sizes for Bathroom Installation

6mm–8mm Diamond Drill Bits

These smaller sizes are commonly used for:

• Shower accessories
• Towel racks
• Glass clips
• Bathroom hardware
• Wall anchors

10mm–20mm Diamond Drill Bits

Medium sizes are suitable for:

• Mounting brackets
• Plumbing supports
• Larger anchors
• Fixture installation

25mm–50mm Diamond Hole Saws

These sizes are commonly used for:

• Water pipes
• Electrical openings
• Shower connections
• Plumbing penetrations

60mm–110mm Diamond Core Bits

Large diameter bits are designed for:

• Drain openings
• Toilet pipe connections
• Large plumbing holes
• Specialized installation requirements

For professional bathroom installers, having multiple sizes available is important because one project can easily require several different hole diameters.

Recommended Speed Settings for Diamond Tile Drill Bits

Running a diamond drill bit at the wrong speed can reduce tool life and increase the chance of tile damage.

Generally, larger diameter bits should run at lower speeds because they create more friction and heat.

Recommended RPM ranges:

• 6–12mm bits: 800–1200 RPM
• 14–30mm bits: 600–900 RPM
• 35–60mm bits: 400–700 RPM
• 70–110mm bits: 300–500 RPM



For porcelain tile drilling, speed control is only part of the process. Proper technique is equally important.

Tips for Better Diamond Bit Performance

Use water cooling whenever possible

Water helps control heat, removes drilling debris, and extends the life of the diamond segments.

Do not force the drill

Diamond tools work by grinding material away. Excessive pressure creates unnecessary heat and can shorten the life of the bit.

Start carefully on smooth porcelain surfaces

Porcelain tiles often have a polished surface that can cause the bit to move when starting. A drilling guide or angled starting technique helps create a clean entry point.

Diamond Saw Blades and Grinding Discs for Tile Cutting

Drilling holes is only one part of bathroom installation. Tile installers also need to cut and adjust tiles around:

• Shower niches
• Wall corners
• Floor edges
• Drain areas
• Irregular shapes

A quality diamond blade for porcelain tile helps achieve cleaner cuts with fewer chips.

For angle grinder applications, the 125mm diamond disc is one of the most common sizes used by professionals.

A double-sided diamond cutting and grinding disc provides additional flexibility because it can be used for both:

• Cutting porcelain and ceramic tiles
• Smoothing rough edges
• Making small adjustments after cutting

This reduces the need to constantly switch between different accessories during installation.

Why Buying Individual Diamond Tools Can Become Expensive

Many installers start by buying tools only when a specific job requires them. While this may seem convenient, the cost can quickly add up.

A bathroom project may require:

• Several diamond drill bit sizes
• Different cutting accessories
• Grinding tools
• Separate storage cases

Over time, individual purchases create three common problems:

Higher Replacement Costs

Frequently used sizes wear faster and often need replacement. Buying individual pieces repeatedly can cost more than investing in a complete set.

Poor Tool Organization

Loose drill bits and discs are easy to misplace, especially when moving between job sites.

Limited Preparation Before Jobs

Arriving at a project without the correct size can delay installation and create unnecessary downtime.

For contractors who regularly install tile, a complete diamond tool kit is a more efficient solution.

DIASHARK Diamond Tool Kit for Professional Tile Installers

To simplify tile installation work, DIASHARK developed a professional diamond tool aluminum case kit designed for bathroom renovation and tile applications.

The kit includes:

• Diamond drill bits from 6mm to 100mm
• Multiple sizes for common tile installation requirements
• A 125mm double-sided diamond cutting and grinding disc
• A durable aluminum storage case for organized transportation

Instead of purchasing separate tools for each project, installers can keep the most commonly used diamond accessories together in one complete system.

Whether drilling small mounting holes, creating plumbing openings, cutting porcelain tiles, or finishing tile edges, the DIASHARK diamond tool kit provides a practical solution for everyday tile installation work.
